PRODUCT PARAMETER
L02C-032E 100W 3°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
2 |
26162 | 40468 | 0.22 | |
4 |
6451 | 10117 | 0.44 | |
6 |
2907 | 4496 | 0.66 | |
8 |
1635 | 2529 | 0.88 | |
10 |
1046 | 1619 | 1.1 |
L02C-032E 100W 5°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 11911 | 17741 | 0.36 | |
8 | 2978 | 4435 | 0.73 | |
12 | 1323 | 1971 | 1.09 | |
16 | 744 | 1109 | 1.46 | |
20 | 476 | 709 | 1.82 |
L02C-072E 150W 7°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 11108 | 17189 | 0.71 | |
8 | 2777 | 4297 | 1.42 | |
12 | 1234 | 1910 | 2.15 | |
16 | 694 | 1074 | 2.86 | |
20 | 444 | 687 | 3.58 |
L02C-072E 150W 15°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 5902 | 8799 | 0.97 | |
8 | 1476 | 2200 | 1.94 | |
12 | 655 | 977 | 2.91 | |
16 | 368 | 549 | 3.88 | |
20 | 236 | 351 | 4.85 |
L02C-072E 150W 25°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 2209 | 3281 | 1.88 | |
8 | 552 | 820 | 3.77 | |
12 | 245 | 364 | 5.66 | |
16 | 138 | 205 | 7.55 | |
20 | 88 | 131 | 9.43 |
L02C-072E 150W 40°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 1504 | 2957 | 2.74 | |
8 | 376 | 739 | 5.48 | |
12 | 167 | 328 | 8.22 | |
16 | 94 | 184 | 10.96 | |
20 | 22 | 118 | 13.7 |
L02C-072E 150W 60°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
4 | 407 | 709 | 4.74 | |
8 | 106 | 177 | 9.48 | |
12 | 47 | 78 | 14.23 | |
16 | 26 | 44 | 18.97 | |
20 | 17 | 28 | 23.72 |
L02C-072C 150W 90°
(h)y |
Eavg(lx) |
Emax[lx] |
D[m] |
|
1 |
1186 | 4044 |
3.07 |
|
2 |
296 | 1011 |
6.14 |
|
3 |
131 | 449 |
9.21 |
|
4 |
74 | 252 |
12.29 |
|
5 |
47 | 161 |
15.36 |
ACCESSORIES
L02C-016E
|
Rated Power |
Input Voltage |
LED Quantity |
Luminous Flux |
Optical Angle |
Net Weight |
Lamp Size |
Gross Weight/Packing Size |
120W |
AC 220V |
16 pcs/RGBW |
4340 lm |
15°/25°/40°/60° |
7.9kg |
425x320x195mm |
9.1kg/520x390x260(1pcs/box) |
L02C-020E
|
Rated Power |
Input Voltage |
LED Quantity |
Luminous Flux |
Optical Angle |
Net Weight |
Lamp Size |
Gross Weight/Packing Size |
150W |
AC 220V |
20pcs/RGBW |
5425lm |
15°/25°/40°/60° |
8.0kg |
425x320x195mm |
9.2kg/520x390x260(1pcs/box) |
L02C-032E
|
Rated Power |
Input Voltage |
LED Quantity |
Luminous Flux |
Optical Angle |
Net Weight |
Lamp Size |
Gross Weight/Packing Size |
3000/4000/5700K |
100W |
AC 220V |
32 pcs |
6779lm |
3°/5° |
7.9kg |
425x320x195mm |
9.1kg/520x390x260(1pcs/box) |
L02C-056E
|
Rated Power |
Input Voltage |
LED Quantity L |
umlnous Flux |
Optical Angle |
Net Weight |
Lamp Size |
Gross Weight/Packing Size |
3000/4000K/RGBW |
120W |
AC 220V |
56 pcs |
11503lm |
7°/10/15/25/4060/90° 15x55°/15x30°/15x45° 4x50°/13x40°/30x60° |
7.9kg |
425x320x195mm |
9.1kg/520x390x260(1pcs/box) |
L02C-072E
|
Rated Power |
Input Voltage |
LED Quantity L |
uminous Flux |
Optical Angle |
Net Weight |
Lamp Size |
Gross Weight/Packing Size |
3000/4000K/RGBW |
150W |
AC 220V |
72 pcs |
14971lm |
7°/10°/15254060/90° 15x55°/15x30°/15x45° 4x50°/13x40°/30x60° |
8.0kg |
425x320x195mm |
9.2kg/520x390x260(1pcs/box) |
